NM400 NM450 NM500 High Hardness Wear Resistant Steel Plate Supplier for Quarry Equipment

NM400 NM450 NM500 High Hardness Wear Resistant Steel Plate Supplier for Quarry Equipment

5 0 Reviews

Brand:
Kangtao
Application:
Ship Plate, Boiler Plate, Container Plate
Certification:
ISO9001
Width:
500-2500mm
Thickness:
3-120mm
Product Name:
Wear Resistant Steel Plate
Standard:
ASTM, JIS, GB, EN
Technique:
Hot Rolled
Type:
Steel Plate
Length:
1-12m or as required

Quantity:
Availability:





Inquire Add to Basket

Product Description

Product Name	Wear Resistant Steel Plate
Thickness	3-120mm
Width	500-2500mm
Length	1-12m or as required
Tolerance	±0.2mm
Standard and Grade	GB: NM360, NM400, NM450, NM500, NM550, NM600, Mn13
	ASTM: AR400, AR450, AR500, AR600
	DIN: XAR360, XAR400, XAR450, XAR500, XAR550, XAR600, Dillidur400, Dillidur500
	NBN: QUARD400, QUARD450, QUARD500
	SFS: RAEX400, RAEX450, RAEX500
	JFE: EH360, EH400, EH450, EH500, EH550, EH600
Applications	1. Engineering machinery and equipment: loaders, bulldozers, xcavators; 2. Handling machinery and equipment: unloading mill chain; plate, hopper liner, grab the edge plate, and automatic tipper tipping plate; 3. Of construction machinery equipment: Cement pusher plate, concrete mixer liner, mixing building lining board, dust collector liner; 4. Metallurgical machinery equipment: iron ore sintering conveying elbow, iron ore sintering machine liner, scraper machine liner; 5. Mining machinery and equipment: Aggregate, stone crusher liner, blade; 6. Other mechanical equipment: Sand barrel, blade, a variety of port machinery wear part 7. Of thermal power equipment: Coal mill lining board Coal, coal conveying pipe, coal distributor frame, unloading equipment lining plate.
Package	Waterproof paper, and steel strip packed. Standard Export Seaworthy Package suit for all kinds of transport, or as customer's requirement.
MOQ	10 tons
Delivery time	8-15 days after deposite received.

Chemical Composition(%)
Steel Grade	C	Si	Mn	P	S	Cr	Ni	Mo	B
NM360	≤0.25	≤0.70	≤1.30	≤0.025	≤0.010	≤1.40	≤1.00	≤0.50	≤0.004
NM400	≤0.25	≤0.70	≤1.60	≤0.025	≤0.010	≤1.40	≤1.00	≤0.50	≤0.004
NM450	≤0.35	≤0.70	≤1.70	≤0.025	≤0.010	≤1.75	≤0.80	≤0.55	0.005-0.006
NM500	≤0.38	≤0.70	≤1.70	≤0.020	≤0.010	≤1.20	≤1.00	≤0.65	0.005-0.006

Mechanical Properties
Steel Grade	Y.S (MPa)	T.S (MPa)	Elongation A5(%)	Impact Test		Hardness
	min	min	min	(°C)	AKV J(min)	HBW
NM360	800	1000	10	-20	30	320-400
NM400	1000	1250	10	-20	30	360-440
NM450	1250	1500	10	-20	30	410-490
NM500	1300	1700	10	-20	30	450-540

Wear-resistant steel plate is a type of steel plate specifically designed to withstand extreme wear conditions. By adding alloying elements such as chromium, molybdenum, manganese and nickel, or adopting advanced heat treatment processes, the durability of the steel plate has been significantly improved. These improvements enhance the hardness, wear resistance and impact strength of the
steel plate, making it an ideal choice for demanding application fields.

Wear-resistant plates are widely used in engineering machinery, mining equipment, conveying systems and steel structure buildings, helping to extend the service life of equipment and significantly reduce maintenance costs.
