Product Name | Wear Resistant Steel Plate |
Thickness | 3-120mm |
Width | 500-2500mm |
Length | 1-12m or as required |
Tolerance | ±0.2mm |
Standard and Grade | GB: NM360, NM400, NM450, NM500, NM550, NM600, Mn13 |
ASTM: AR400, AR450, AR500, AR600 | |
DIN: XAR360, XAR400, XAR450, XAR500, XAR550, XAR600, Dillidur400, Dillidur500 | |
NBN: QUARD400, QUARD450, QUARD500 | |
SFS: RAEX400, RAEX450, RAEX500 | |
JFE: EH360, EH400, EH450, EH500, EH550, EH600 | |
Applications | 1. Engineering machinery and equipment: loaders, bulldozers, xcavators; 2. Handling machinery and equipment: unloading mill chain; plate, hopper liner, grab the edge plate, and automatic tipper tipping plate; 3. Of construction machinery equipment: Cement pusher plate, concrete mixer liner, mixing building lining board, dust collector liner; 4. Metallurgical machinery equipment: iron ore sintering conveying elbow, iron ore sintering machine liner, scraper machine liner; 5. Mining machinery and equipment: Aggregate, stone crusher liner, blade; 6. Other mechanical equipment: Sand barrel, blade, a variety of port machinery wear part 7. Of thermal power equipment: Coal mill lining board Coal, coal conveying pipe, coal distributor frame, unloading equipment lining plate. |
Package | Waterproof paper, and steel strip packed. Standard Export Seaworthy Package suit for all kinds of transport, or as customer's requirement. |
MOQ | 10 tons |
Delivery time | 8-15 days after deposite received. |
Chemical Composition(%) | |||||||||
Steel Grade | C | Si | Mn | P | S | Cr | Ni | Mo | B |
NM360 | ≤0.25 | ≤0.70 | ≤1.30 | ≤0.025 | ≤0.010 | ≤1.40 | ≤1.00 | ≤0.50 | ≤0.004 |
NM400 | ≤0.25 | ≤0.70 | ≤1.60 | ≤0.025 | ≤0.010 | ≤1.40 | ≤1.00 | ≤0.50 | ≤0.004 |
NM450 | ≤0.35 | ≤0.70 | ≤1.70 | ≤0.025 | ≤0.010 | ≤1.75 | ≤0.80 | ≤0.55 | 0.005-0.006 |
NM500 | ≤0.38 | ≤0.70 | ≤1.70 | ≤0.020 | ≤0.010 | ≤1.20 | ≤1.00 | ≤0.65 | 0.005-0.006 |
Mechanical Properties | ||||||
Steel Grade | Y.S (MPa) | T.S (MPa) | Elongation A5(%) | Impact Test | Hardness | |
min | min | min | (°C) | AKV J(min) | HBW | |
NM360 | 800 | 1000 | 10 | -20 | 30 | 320-400 |
NM400 | 1000 | 1250 | 10 | -20 | 30 | 360-440 |
NM450 | 1250 | 1500 | 10 | -20 | 30 | 410-490 |
NM500 | 1300 | 1700 | 10 | -20 | 30 | 450-540 |
Product Name | Wear Resistant Steel Plate |
Thickness | 3-120mm |
Width | 500-2500mm |
Length | 1-12m or as required |
Tolerance | ±0.2mm |
Standard and Grade | GB: NM360, NM400, NM450, NM500, NM550, NM600, Mn13 |
ASTM: AR400, AR450, AR500, AR600 | |
DIN: XAR360, XAR400, XAR450, XAR500, XAR550, XAR600, Dillidur400, Dillidur500 | |
NBN: QUARD400, QUARD450, QUARD500 | |
SFS: RAEX400, RAEX450, RAEX500 | |
JFE: EH360, EH400, EH450, EH500, EH550, EH600 | |
Applications | 1. Engineering machinery and equipment: loaders, bulldozers, xcavators; 2. Handling machinery and equipment: unloading mill chain; plate, hopper liner, grab the edge plate, and automatic tipper tipping plate; 3. Of construction machinery equipment: Cement pusher plate, concrete mixer liner, mixing building lining board, dust collector liner; 4. Metallurgical machinery equipment: iron ore sintering conveying elbow, iron ore sintering machine liner, scraper machine liner; 5. Mining machinery and equipment: Aggregate, stone crusher liner, blade; 6. Other mechanical equipment: Sand barrel, blade, a variety of port machinery wear part 7. Of thermal power equipment: Coal mill lining board Coal, coal conveying pipe, coal distributor frame, unloading equipment lining plate. |
Package | Waterproof paper, and steel strip packed. Standard Export Seaworthy Package suit for all kinds of transport, or as customer's requirement. |
MOQ | 10 tons |
Delivery time | 8-15 days after deposite received. |
Chemical Composition(%) | |||||||||
Steel Grade | C | Si | Mn | P | S | Cr | Ni | Mo | B |
NM360 | ≤0.25 | ≤0.70 | ≤1.30 | ≤0.025 | ≤0.010 | ≤1.40 | ≤1.00 | ≤0.50 | ≤0.004 |
NM400 | ≤0.25 | ≤0.70 | ≤1.60 | ≤0.025 | ≤0.010 | ≤1.40 | ≤1.00 | ≤0.50 | ≤0.004 |
NM450 | ≤0.35 | ≤0.70 | ≤1.70 | ≤0.025 | ≤0.010 | ≤1.75 | ≤0.80 | ≤0.55 | 0.005-0.006 |
NM500 | ≤0.38 | ≤0.70 | ≤1.70 | ≤0.020 | ≤0.010 | ≤1.20 | ≤1.00 | ≤0.65 | 0.005-0.006 |
Mechanical Properties | ||||||
Steel Grade | Y.S (MPa) | T.S (MPa) | Elongation A5(%) | Impact Test | Hardness | |
min | min | min | (°C) | AKV J(min) | HBW | |
NM360 | 800 | 1000 | 10 | -20 | 30 | 320-400 |
NM400 | 1000 | 1250 | 10 | -20 | 30 | 360-440 |
NM450 | 1250 | 1500 | 10 | -20 | 30 | 410-490 |
NM500 | 1300 | 1700 | 10 | -20 | 30 | 450-540 |
Wear-resistant steel plate is a type of steel plate specifically designed to withstand extreme wear conditions. By adding alloying elements such as chromium, molybdenum, manganese and nickel, or adopting advanced heat treatment processes, the durability of the steel plate has been significantly improved. These improvements enhance the hardness, wear resistance and impact strength of the
steel plate, making it an ideal choice for demanding application fields.
Wear-resistant steel plate is a type of steel plate specifically designed to withstand extreme wear conditions. By adding alloying elements such as chromium, molybdenum, manganese and nickel, or adopting advanced heat treatment processes, the durability of the steel plate has been significantly improved. These improvements enhance the hardness, wear resistance and impact strength of the
steel plate, making it an ideal choice for demanding application fields.
